KubeVirtBMC: Enabling Bare-metal Provisioning for KubeVirt Virtual Machines

When you provision bare-metal servers using software, such as Tinkerbell, Metal3, or even Foreman, you need a BMC (Baseboard Management Controller) to power them on, set the boot order, and control them remotely. But what if you want to test your provisioning software without real hardware? Moreover, what if your test environment runs on Kubernetes with KubeVirt?

KubeVirtBMC solves this problem. It provides your virtual machines with a virtual BMC that mimics a real BMC. Your provisioning software won’t be able to distinguish between them. That also implies that no source code-level modifications to the provisioning software are required for the entire workflow to run on virtual machines.

The Problem

Let me show you what bare-metal provisioning software expects:

flowchart LR
    subgraph "Bare-Metal Provisioning"
        Tool[Provisioning Software
Tinkerbell/Metal3] -->|IPMI/Redfish| BMC[Server BMC]
        BMC -->|Controls| Server[Bare-metal Server]
    end

These bare-metal provisioning software needs BMC to:

Power on servers to start OS installation
Set servers to boot from network (PXE)
Check if servers are on or off
Reset servers when needed

But KubeVirt virtual machines don’t have BMCs. To test with KubeVirt, you’d need to modify your provisioning software or use workarounds. Other virtualization platforms address this with auxiliary software such as VirtualBMC or sushy-tools from OpenStack, but these don’t integrate well with KubeVirt because they interact directly with libvirt. However, KubeVirt wraps libvirt into individual launcher pods, making it hard to access from other pods or even externally.

How KubeVirtBMC Helps

KubeVirtBMC creates a BMC emulator for each virtual machine. The controller watches for VirtualMachineBMC custom resources and automatically creates both a BMC pod and a Service to expose it. Here’s how it works:

KubeVirtBMC architecture

Each virtual machine gets:

A BMC pod that understands IPMI and Redfish
A Service with its own IP address as the cluster-wide entry point
Full BMC functionality for provisioning

Step-by-Step Setup Guide

Let’s set up KubeVirtBMC and try it out. I recommend using Harvester HCI for setup because it provides all the necessary components in a single package (disclosure: I am one of the developers behind the project/product.) If you want to try KubeVirtBMC with something else, check the following prerequisites.

What You Need

Before starting, make sure you have:

Kubernetes cluster with virtualization support on each node
KubeVirt installed and working
A storage provider installed
(Optional) Multus installed for networking, serving the provisioning purpose

Step 0: Set Up KubeVirt CI

If you don’t want to use a full-fledged solution like Harvester, you can still try KubeVirtBMC on any server or in a virtual machine (with nested virtualization enabled, of course). KubeVirt CI can be a handy tool when developing KubeVirt. It provides the same convenience for setting up the environment to try out KubeVirtBMC.

git clone https://github.com/kubevirt/kubevirt.git
cd kubevirt/
export KUBEVIRT_PROVIDER=k8s-1.34
export KUBEVIRT_NUM_NODES=2
export KUBEVIRT_MEMORY_SIZE=6144M
export FEATURE_GATES=DeclarativeHotplugVolumes
export KUBEVIRT_NUM_SECONDARY_NICS=1
make cluster-up

This gives you a running Kubernetes cluster, but without KubeVirt installed. Now, build and deploy KubeVirt into the cluster (this will take some time).

make cluster-sync

After KubeVirt is installed, we can set up the kubeconfig file and some more handy shortcuts and tools:

export KUBECONFIG=$(./kubevirtci/cluster-up/kubeconfig.sh)
alias kubectl=./kubevirtci/cluster-up/kubectl.sh
curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

$ kubectl get nodes
NAME     STATUS   ROLES           AGE    VERSION
node01   Ready    control-plane   107m   v1.34.3
node02   Ready    worker          106m   v1.34.3
$ kubectl get pods -A
NAMESPACE      NAME                               READY   STATUS    RESTARTS   AGE
cdi            cdi-apiserver-6cc6bcdc46-2zgkf     1/1     Running   0          5m33s
cdi            cdi-deployment-59945cb874-hj5rh    1/1     Running   0          5m33s
cdi            cdi-operator-697fd6d5b4-c6tns      1/1     Running   0          107m
cdi            cdi-uploadproxy-7787b9cc65-v2phk   1/1     Running   0          5m33s
default        local-volume-provisioner-thhwb     1/1     Running   0          107m
default        local-volume-provisioner-x692r     1/1     Running   0          106m
kube-flannel   kube-flannel-ds-kv2gq              1/1     Running   0          107m
kube-flannel   kube-flannel-ds-r62tt              1/1     Running   0          107m
kube-system    coredns-67d94d8d9b-fxfzd           1/1     Running   0          107m
kube-system    coredns-67d94d8d9b-pkg77           1/1     Running   0          107m
kube-system    etcd-node01                        1/1     Running   1          107m
kube-system    kube-apiserver-node01              1/1     Running   1          107m
kube-system    kube-controller-manager-node01     1/1     Running   1          107m
kube-system    kube-network-policies-jp6fg        1/1     Running   0          107m
kube-system    kube-network-policies-wf9wv        1/1     Running   0          107m
kube-system    kube-proxy-pk42m                   1/1     Running   0          107m
kube-system    kube-proxy-vmk9z                   1/1     Running   0          107m
kube-system    kube-scheduler-node01              1/1     Running   1          107m
kubevirt       disks-images-provider-97v99        1/1     Running   0          5m52s
kubevirt       disks-images-provider-lfgj7        1/1     Running   0          5m52s
kubevirt       virt-api-7bd584566b-lzsrh          1/1     Running   0          4m47s
kubevirt       virt-api-7bd584566b-xx4ml          1/1     Running   0          3m50s
kubevirt       virt-controller-94c9f4975-czqsr    1/1     Running   0          4m21s
kubevirt       virt-controller-94c9f4975-g5mvs    1/1     Running   0          4m21s
kubevirt       virt-handler-9cvlm                 1/1     Running   0          4m21s
kubevirt       virt-handler-gkh8d                 1/1     Running   0          4m21s
kubevirt       virt-operator-78b6c8944-c7xp6      1/1     Running   0          5m49s
kubevirt       virt-operator-78b6c8944-nbwdl      1/1     Running   0          5m49s
$ helm list -A
NAME    NAMESPACE       REVISION        UPDATED STATUS  CHART   APP VERSION

Step 1: Install cert-manager

KubeVirtBMC needs certificates for its webhook server. Install cert-manager first:

# Add the repository
helm repo add jetstack https://charts.jetstack.io
helm repo update

# Install cert-manager
helm upgrade --install cert-manager jetstack/cert-manager \
    --namespace=cert-manager \
    --create-namespace \
    --set=crds.enabled=true

Step 2: Install KubeVirtBMC

# Add KubeVirtBMC repository
helm repo add kubevirtbmc https://charts.zespre.com/
helm repo update

# Install KubeVirtBMC
helm upgrade --install kubevirtbmc kubevirtbmc/kubevirtbmc \
    --namespace=kubevirtbmc-system \
    --create-namespace

# Wait for the controller manager pod becomes ready
kubectl -n kubevirtbmc-system wait --for=condition=Ready pods \
    -l app.kubernetes.io/name=kubevirtbmc

KubeVirtBMC is now ready to serve.

Step 3: Create a Test Virtual Machine

First, create a disk for the virtual machine:

cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: test-server-disk
  namespace: default
spec:
  accessModes:
  - ReadWriteOnce
  resources:
    requests:
      storage: 20Gi
EOF

Now create the VirtualMachine resource:

cat <<EOF | kubectl apply -f -
apiVersion: kubevirt.io/v1
kind: VirtualMachine
metadata:
  name: test-server
  namespace: default
spec:
  runStrategy: Always
  template:
    spec:
      domain:
        cpu:
          cores: 2
        memory:
          guest: 2Gi
        devices:
          disks:
          - name: rootdisk
            disk:
              bus: virtio
          - cdrom:
              bus: sata
            name: cdrom
          - name: cloudinit
            disk:
              bus: virtio
          interfaces:
          - name: default
            masquerade: {}
      networks:
      - name: default
        pod: {}
      volumes:
      - name: rootdisk
        persistentVolumeClaim:
          claimName: test-server-disk
      - name: cloudinit
        cloudInitNoCloud:
          userData: |
            #cloud-config
            hostname: test-server
EOF

The virtual machine should start immediately, but it lacks a viable boot device. We will later perform the ISO installation using the Redfish virtual media service supported by KubeVirtBMC.

Step 4: Enable BMC for the Virtual Machine

Now, the important part: create a BMC for your virtual machine. Since the VirtualMachineBMC resource references both the VirtualMachine resource and the credential Secret, you need to create a Secret containing the login username and password as well.

cat <<EOF | kubectl apply -f -
---
apiVersion: v1
kind: Secret
metadata:
  name: bmc-auth-secret
  namespace: default
stringData:
  username: admin
  password: password
---
apiVersion: bmc.kubevirt.io/v1beta1
kind: VirtualMachineBMC
metadata:
  name: test-bmc
  namespace: default
spec:
  virtualMachineRef:
    name: test-server
  authSecretRef:
    name: bmc-auth-secret
EOF

Check if the BMC is ready:

$ kubectl wait --for=condition=Ready virtualmachinebmcs test-bmc
virtualmachinebmc.bmc.kubevirt.io/test-bmc condition met

# Get BMC status
$ kubectl get virtualmachinebmcs test-bmc -o yaml
apiVersion: bmc.kubevirt.io/v1beta1
kind: VirtualMachineBMC
metadata:
  annotations:
    kubectl.kubernetes.io/last-applied-configuration: |
      {"apiVersion":"bmc.kubevirt.io/v1beta1","kind":"VirtualMachineBMC","metadata":{"annotations":{},"name":"test-bmc","namespace":"default"},"spec":{"authSecretRef":{"name":"bmc-auth-secret"},"virtualMachineRef":{"name":"test-server"}}}
  creationTimestamp: "2026-02-14T03:46:21Z"
  generation: 1
  name: test-bmc
  namespace: default
  resourceVersion: "514248"
  uid: 4a9decb2-5699-428d-9a4f-b7f468ec20fe
spec:
  authSecretRef:
    name: bmc-auth-secret
  virtualMachineRef:
    name: test-server
status:
  clusterIP: 10.100.46.80
  conditions:
  - lastTransitionTime: "2026-02-14T03:46:21Z"
    message: VirtualMachine "test-server" is available
    reason: VirtualMachineFound
    status: "True"
    type: VirtualMachineAvailable
  - lastTransitionTime: "2026-02-14T03:46:21Z"
    message: Secret "bmc-auth-secret" is available
    reason: SecretFound
    status: "True"
    type: SecretAvailable
  - lastTransitionTime: "2026-02-14T03:46:21Z"
    message: ClusterIP assigned to the Service
    reason: ServiceReady
    status: "True"
    type: Ready

# Get the BMC IP address
$ BMC_IP=$(kubectl get virtualmachinebmcs test-bmc -o jsonpath='{.status.clusterIP}')
$ echo "BMC IP address: $BMC_IP"
BMC IP address: 10.100.46.80

Step 5: Test with IPMI Commands

Let’s test if the BMC works. Create a test pod for running client commands:

kubectl run -it --rm ipmi-test --image=alpine -- sh

Inside the test pod:

# Install ipmitool
apk add ipmitool

# Set the BMC IP (use the IP from the previous step)
BMC_ENDPOINT=test-server-virtbmc.default.svc

# Check power status
ipmitool -H "$BMC_ENDPOINT" -U admin -P password power status

# Power off
ipmitool -H "$BMC_ENDPOINT" -U admin -P password power off

# Power on
ipmitool -H "$BMC_ENDPOINT" -U admin -P password power on

# Set to boot from network (PXE)
ipmitool -H "$BMC_ENDPOINT" -U admin -P password chassis bootdev pxe

# Reset the server
ipmitool -H "$BMC_ENDPOINT" -U admin -P password power reset

Step 6: Test with Redfish

KubeVirtBMC also supports Redfish. Test it with curl:

kubectl run -it --rm curl-test --image=curlimages/curl -- sh

Inside the test pod, we will mount an installation ISO image on a virtual machine with an empty disk to perform an interactive installation.

# Set variables
BMC_ENDPOINT=test-server-virtbmc.default.svc

# Get system info
curl -u admin:password "http://$BMC_ENDPOINT/redfish/v1/Systems/1"

# Attach an ISO image from remote (download-based)
curl -u admin:password \
    -X POST \
    -H "Content-Type: application/json" \
    -d '{"Image": "https://releases.ubuntu.com/noble/ubuntu-24.04.3-live-server-amd64.iso", "Inserted": true}' \
    "http://$BMC_ENDPOINT/redfish/v1/Managers/BMC/VirtualMedia/CD1/Actions/VirtualMedia.InsertMedia"

# Power on
curl -u admin:password \
    -X POST \
    -H "Content-Type: application/json" \
    -d '{"ResetType":"ForceRestart"}' \
    "http://$BMC_ENDPOINT/redfish/v1/Systems/1/Actions/ComputerSystem.Reset"

It will take some time for the virtual machine to start again because the virtual media we are attaching will first be downloaded, then attached to the virtual machine as a CD-ROM volume. During this preparation period, the status of the VirtualMachine resource should display WaitingForVolumeBinding:

$ kubectl get vms test-server
NAME          AGE   STATUS                    READY
test-server   25h   WaitingForVolumeBinding   False

How the Magic Works

When you send an IPMI/Redfish request, here’s what happens:

sequenceDiagram
    participant PT as Provisioning Tool
    participant SVC as K8s Service
    participant BMC as BMC Pod
    participant API as K8s API
    participant VM as Virtual Machine

    PT->>SVC: IPMI/Redfish: Power On
    SVC->>BMC: Forward Request
    BMC->>BMC: Parse IPMI/Redfish
    BMC->>API: Start VM
    API->>VM: Change State
    VM-->>API: Running
    API-->>BMC: Success
    BMC-->>SVC: IPMI/Redfish Response
    SVC-->>PT: Power On Success

The BMC pod translates IPMI and Redfish requests to Kubernetes API calls. Simple but effective!

Using Cloud-Native Provisioning Tools

Now you can use these virtual machines with cloud-native bare-metal provisioning tools like Tinkerbell, Metal3, and others. Because they run in Kubernetes, they can access BMC services directly within the cluster. More details and use case demonstrations will be available in upcoming articles.

Example: Tinkerbell

In your Machine resource definition:

---
apiVersion: v1
kind: Secret
metadata:
  name: machine-auth
  namespace: tinkerbell
type: kubernetes.io/basic-auth
stringData:
  username: admin
  password: password
---
apiVersion: bmc.tinkerbell.org/v1alpha1
kind: Machine
metadata:
  name: test-server
  namespace: tinkerbell
spec:
  connection:
    host: test-server-virtbmc.default.svc
    port: 80
    authSecretRef:
      name: machine-auth
      namespace: tinkerbell
    providerOptions:
      redfish:
        port: 80

Example: Metal3

In your BareMetalHost resource definition:

---
apiVersion: v1
kind: Secret
metadata:
  name: baremetalhost-auth
type: Opaque
stringData:
  username: admin
  password: password
---
apiVersion: metal3.io/v1alpha1
kind: BareMetalHost
metadata:
  name: test-server
spec:
  online: true
  bootMACAddress: 36:4e:ba:6f:9e:bf
  bmc:
    address: redfish+http://test-server-virtbmc.default.svc/redfish/v1/Systems/1
    credentialsName: baremetalhost-auth
  rootDeviceHints:
    deviceName: /dev/vda

It is also possible to perform cross-cluster provisioning. For example, if you have a management cluster where the bare-metal provisioning software is deployed, and the to-be-provisioned KubeVirt virtual machines are in a different cluster, KubeVirtBMC works well with the Ingress API. Simply add Ingress resources for each VirtualMachineBMC you want to expose, and you can access them externally.

What’s Next

KubeVirtBMC is actively evolving. You can view the ongoing feature developments here. The project continues to grow and is here to stay.

Conclusion

KubeVirtBMC bridges the gap between bare-metal provisioning and virtual environments. It lets you test your infrastructure automation without physical hardware, using the same tools and workflows. If you’ve ever wondered how to adapt your existing bare-metal provisioning solutions to modern cloud-native infrastructure like KubeVirt, check out the project at kubevirtbmc/kubevirtbmc. Contributions and feedback are welcome!

Happy provisioning!
